WAVE SOLDERING
MACHINE
"The Wave that Bonds — Strong, Clean, and Reliable."
ETS - Wave Solder Machine
ETS - Wave Solder Machine
Overview
The ETS-WSM 300 Wave Soldering Machine is a reliable through-hole soldering solution designed for stable, uniform, and high-quality solder joints. Equipped with a precise fluxing system, an efficient preheating zone, and a high-stability solder wave, it ensures excellent solder penetration and reduced defects like bridging and icicles. With adjustable conveyor width, PID-controlled temperature, and compatibility with both leaded and lead-free solder, it supports consistent, repeatable production for EMS, automotive, EV, LED, and consumer electronics manufacturing.
- Ensures smooth, consistent wave flow for strong solder penetration and highly reliable DIP solder joints.
- Uniform flux application reduces bridging, icicles, and soldering defects while improving overall process stability.
- Multiple preheating stages support proper thermal activation, enhancing wetting and reducing thermal shock on components.
- Maintains stable solder pot temperature for both leaded and lead-free alloys, ensuring consistent solder quality.
- Supports a wide range of PCB sizes, enabling flexible manufacturing for different product categories.
- Designed for long-term durability, corrosion resistance, and stable thermal performance.
- Features safety interlocks, protective viewing windows, and fume extraction compatibility.
Complete Machine
| Parameter | Specification |
|---|---|
| Model | : ETS-WS300 |
| Size | : L3400×W1240×H1650mm |
| Weight | : 900KG |
| Power Supply | : AC380V/50Hz (50A) |
| Starting Power | : 23KW |
| Normal Operating Power | : 8KW |
| Control System | : Touch Screen |
| PCB Transport Height | : 760±20mm |
Spray System
| Parameter | Specification |
|---|---|
| Transmission Mode | : Stepper Motor + Digital Driver + Linear Guide Rail |
| Spray Pressure | : 0.25MPa-0.4MPa |
| Nozzle Type | : A100-1.0 |
| Flow Control Mode | : Flowmeter |
| Flux Storage Tank | : 5.5L |
Preheating System
| Parameter | Specification |
|---|---|
| Preheating Mode | : Modular full hot air heating |
| Temperature Control Mode | : PID + SSR |
| Number of Preheating Zones | : 3 |
| Length of Preheating Zone | : 1350mm |
| Adjustable Temperature Range | : Room temperature - 250°C |
| Preheating Zone Power | : 9KW |
Transportation System
| Parameter | Specification |
|---|---|
| Width of PCB Board | : 50mm-300mm |
| PCB Transfer Direction | : Left to Right (L → R) |
| Transmission Speed Range | : 200-2200mm/min |
| PCB Component Pin Length | : <10mm |
| Speed Control Mode | : Touch screen control, digital speed regulation |
| Welding Angle | : 4°-7° |
| Guide rail width adjustment method | : Manual width adjustment |
Tin Furnace System
| Parameter | Specification |
|---|---|
| Tin Furnace Type | : External heated tin furnace |
| Tin Furnace Material | : 316L Stainless Steel δ=4.0mm |
| Tin Furnace Power | : 4500Wx3=13.5KW |
| Wave Crest Type | : Double wave (turbulence wave + advection wave) |
| Wave Crest Height | : 0-12mm |
| Solder Temperature | : Room temperature - 320°C |
| Tin Furnace Capacity | : 280KG |
| Tin Melting Time | : 70min (at 245°C) |
| Tin Furnace Control Mode | : PID + SSR |
| Lifting Mode of Tin Furnace | : Hand Movement |
| Access Mode of Tin Furnace | : Hand Movement |
| Tin Furnace Starts Regularly | : Yes |
Cleaning System
| Parameter | Specification |
|---|---|
| Cleaning Agent | : Alcohol |
| Nozzle Alcohol Tank Capacity | : 2.4L |
| Capacity of Drawer Washing Alcohol Tank | : 2.4L |
Cooling System
| Parameter | Specification |
|---|---|
| Cooling Method | : Natural Air Cooling |
