ETS - Semi Automatic Stencil Printer - 550
ETS - Semi Automatic Stencil Printer - 550
Overview
The SP550 is a semi-automatic stencil printer that improves consistency and speed compared to manual printing. With pneumatic squeegee operation and touchscreen control, it is well suited for low- to medium-volume production requiring stable and repeatable solder paste printing.
- High Printing Precision – Automatic squeegee movement ensures uniform solder paste deposition and stable repeatability.
- Touchscreen Control Panel – Easy-to-use interface.
- Pneumatic Operation – Automatic stencil lifting and printing cycle reduce operator fatigue and improve consistency.
- Adjustable Fixtures—Flexible PCB clamping system supports various board sizes.
- High Efficiency—Faster cycle times compared to manual printing, suitable for medium-volume production.
- Durable & Rigid Frame – Strong construction minimizes vibration and ensures stable alignment.
- Cost-Effective Automation—Perfect balance between manual printers (low cost) and fully automatic printers (high cost).
- Compact Design – Saves floor space while providing professional-grade printing capability.
| Parameter | Details |
|---|---|
| Print Table Size | : 320 × 500mm |
| Frame Size | : 370 × 470mm / 420 × 520mm / 550 × 650mm |
| Substrate Size | : 320 × 450mm |
| Substrate Thickness | : 0.2 - 2.2mm |
| Positioning | : Outer or Pin Positioning |
| Minimum Adjustment | : Front/Back ±10mm, Left/Right ±10mm |
| Printing Accuracy | : ±0.02mm |
| Repeatability | : ±0.05mm |
| Minimum Pad Distance | : 0.25mm |
| Air Pressure | : 4 - 6 Kgf/cm² |
| Power Supply | : 110V / 220V, 50Hz / 60Hz, 200W |
| Size (L × W × H) | : 860 × 780 × 1650 mm |
| Weight | : 235Kg |
