ETS - Top 3 Zone & Bottom 2 Zone Reflow Oven
ETS - Top 3 Zone & Bottom 2 Zone Reflow Oven
Overview
The RFO 530 is a hot-air reflow oven designed for precise SMT soldering with enhanced temperature control. It features five temperature zones, allowing smoother and more accurate thermal profiling compared to basic infrared models. The system uses a hot-wind heating method, ensuring uniform heat distribution across the PCB for reliable solder joints. It includes two ventilation cooling zones and supports PCB sizes up to 280 × 280 mm, transported on a 300 mm wide net belt with adjustable speed from 0 to 1500 mm/min using variable frequency drive control. Operating on AC 220V/380V ±10%, 50 Hz, the ZBRF530 requires 7 kW starting power and 2.5 kW operating power, with a heat-up time of about 20 minutes. The overall processing time through the machine ranges from 3.5 to 5.5 minutes. Its temperature can be controlled from ambient to 400°C through a touchscreen interface using PID closed-loop technology. The machine has an outline size of 1700 × 710 × 660 mm and weighs 150 kg, making it a compact yet powerful solution for efficient SMT reflow soldering.
- 5 Temperature Zones for precise and stable thermal profiling.
- Hot-wind heating method providing uniform heat distribution across the PCB.
- 2 Ventilation Cooling Zones for controlled cooling and improved solder joint quality.
- Supports PCB size up to 280 × 280 mm with a 300 mm wide net belt.
- Variable Conveyor Speed (0–1500 mm/min) using a Variable Frequency.
- AC 220V/380V ±10%, 50 Hz Input Power.
- 7 kW starting power and 2.5 kW operating power.
| Type | ZBRF530 |
|---|---|
| Heat Zone Numbers | : 5 Temperature Zones |
| Heating Method | : Hot Wind |
| Number of Cooling Zones | : 2 Ventilation Cooling |
| Length of Heating Zones | : 960 mm |
| Width of Net Belt | : 300 mm |
| PCB Dimension | : Max. 280 × 280 mm |
| Height of Net Belt | : 300 ± 20 mm |
| Transport Speed of Net Belt | : 0–1500 mm/MIN (Variable Frequency Drive) |
| Transport Direction of Net Belt | : Left → Right (Right → Left) |
| Input Power | : AC220V/380V ±10% 50Hz |
| Starting Power | : 7 KW |
| Operating Power | : 2.5 KW |
| Heating Up Time | : About 20 min |
| Time of Passing Through the Machine | : 3.5 – 5.5 min |
| Temperature Control Range | : Ambient Temperature – 400°C |
| Temperature Control Method | : Touch Screen Control (PID Closed-Loop Calculation) |
| Outline Size | : L1700 × W710 × H660 mm |
| Weight | : 150 Kg |
